"2S2/0-HEX-M" Double Wire Lug (2/0-14 AWG) & FLEX Wire (1/0-14 AWG)
- Buy 160 for $1.86 each and save 26%
- Buy 500 for $1.39 each and save 44%
"2S2/0-HEX-M" 2/0-14 AWG wire range, and FLEX wire, 1/0-14 AWG, G-K including mm2 class 5, 2 barrel, aluminum or copper wire, CU9AL, 90C temperature rating, single 1/4" bolt (6mm) mounting hole, UL Listed, CSA Certified. 5mm Metric Hex Socket Screw. Made in the USA from domestic and imported parts.
Use of Ferrules (UL Listed) on 1/0-14 AWG
Convenient inspection window to visually inspect full conductor insertion
Made with 6061-T6 aluminum to provide maximum electrical contact and performance
Electro tin-plated, to warrant against corrosion
Plated aluminum or steel screw provides durable long lasting contact between the conductor and connector
|For More Information Click the Icons Below|
|2/0-3 AWG||50 IN. LBS.|
|4-6 AWG||45 IN. LBS.|
|8 AWG||40 IN. LBS.|
|10-14 AWG||35 IN. LBS.|
75 IN. LBS.
55 IN. LBS.
50 IN. LBS.
|8-10 AWG||45 IN. LBS.|
|10-14 AWG||40 IN. LBS.|
|175 Amp 75C Cu Wire|
|195 Amp 90C Cu Wire|
|135 Amp 75C Al Wire|
|150 Amp 90C Al Wire|
|Per Wire in Power Distribution or Collection Mode|
|Number of Wires||2 Wires|
|AWG Wire Range||2/0 - 14 AWG|
|FLEX Wire Range||1/0-14 AWG|
|Screw Type||Hex Socket|
|CSA Canadian Standards Association Certified||Yes|
|UL||UL Listed (UL)|
